Reduce Mechanical Stress & Energy Costs – Intelligent Soft Start Technology for Reliable, Energy-Efficient AC Compressor Operation

What is a Bypass Soft Starter?

A bypass soft starter is an electronic motor control device that provides smooth acceleration and energy-efficient operation through its unique two-stage design:

Soft Start Phase
During initial startup, solid-state thyristors gradually increase voltage to the motor, limiting inrush current to just 300% of rated current (compared to 600-800% with direct-on-line starters). This prevents mechanical stress on couplings, belts, and gears.

Bypass Phase
Once the motor reaches ~90% speed, an integrated contactor automatically engages, creating a direct power path that:

▫︎ Eliminates thyristor voltage drop (saving 2-3% energy)

▫︎ Reduces heat generation in the control cabinet

▫︎ Maintains full voltage operation while preserving protection circuits

How Does It Work?

Bypass soft starters provide precision motor control through four key stages:

Controlled Acceleration

Microprocessor triggers thyristors using voltage ramp/current limit algorithms

Speed Synchronization

Monitors RPM and initiates bypass at 90% speed (adjustable 80-95%)

Seamless Transition

Main contactor engages in <50ms

Continuous Monitoring

Maintains protection against overloads/phase loss even in bypass mode

Technical Highlight:

✓ Zero-voltage switching prevents torque spikes during transition

Why Choose Bypass Soft Starters?

The main benefits from bypass starters:

3% Energy Savings

No thyristor loss during run compared to inline starters

Cooler Operation

Reduces control cabinet cooling needs

5X Longer Thyristor Life

Only active during start/stop

Easy Maintenance

Contactors cost 60% less to replace than thyristor stacks

Proven in HVAC/Compressors

10,000+ installations worldwide

ASF9H Series | Dual-Mode Motor Protection
1 2 3 4 NEXT

FAQ

What is an electronic bypass soft starter?

It’s a motor controller that gradually increases voltage to a three-phase motor during startup, reducing mechanical stress and electrical surges. After reaching full speed, it "bypasses" to direct power, improving efficiency.

How does it differ from a traditional starter or VFD?

Unlike VFDs (which control speed continuously), soft starters only manage startup/shutdown. Bypass models save energy by switching to direct connection after startup.

Can this soft starter be used for AC compressors?

Yes! It’s designed for high-torque applications like AC compressors, pumps, and industrial motors, reducing inrush current and wear.

What motor sizes (HP/kW) does it support?

Specify your model’s range (e.g., 5–500 HP). Always check the datasheet for compatibility.

How do I wire the soft starter to a three-phase motor?

Follow the wiring diagram in the manual, connecting input power, motor terminals, and bypass contacts. Ensure correct phase sequence.

Can I adjust the startup time?

Yes. Use the control panel or potentiometer to set ramp-up time (typically 1–30 seconds) based on motor load.

Why does my motor jerk during startup?

Possible causes:
• Too short ramp time.
• Incorrect voltage settings.
• Mechanical load misalignment.

The bypass fails to engage—what should I check?

Verify:
• Bypass relay/contactor functionality.
• Motor reaches full speed before bypass.
• No fault codes on the display.

Does the soft starter need cooling?

Ensure adequate ventilation. Some models have built-in fans; avoid obstructing airflow.

Can it protect against phase loss or overload?

Yes. Most models include protections for phase imbalance, overload, and short circuits.

Is there a warranty?

Typically 1–3 years, depending on manufacturer. Register the product for full coverage.
